DGPI-15S20Ah-015 AGV Lithium Battery
time：2025-01-17
Parameters：
Brand Guarantee: optional Brand Cell
Long Life: battery Cycle Times> 2000
System Security: equipped with Smart BMS to Monitor the Battery Status in Real Time and Protect the Battery
| Model |
DGPI-15S20Ah-015 |
| nominal Voltage |
48V |
| nominal capacity |
20Ah |
| charging current |
≤ 15A |
| discharge current |
≤ 25A |
| charging voltage |
54.75V |
| Cell specifications |
lithium iron phosphate |
| finished product internal resistance |
≤ 40 Mohm |
| battery weight |
16.0Kg ± 3.0Kg |
| Product Size | l350mm*W338mm*H140mm(Max) |
| communication mode |
RS232/RS485 |
| lithium battery protection |
short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, equalization, etc. |
