DGPI-8S40Ah-023 Handling Robot Lithium Battery Pack
time：2025-02-26
Parameters：
Specifications DGPI-8S40Ah-023
1 Brand Assurance: optional Brand Cell
2 Long Life: battery Cycle Times> 2000
3 System Security: equipped with Smart BMS to Monitor the Battery Status in Real Time and Protect the Battery
| Model |
DGPI-8S40Ah-023 |
| battery Specification |
8S1P/25.6V/40Ah |
| nominal Voltage |
24V |
| nominal capacity |
40Ah |
| charging voltage |
29.2V |
| charging current |
≤ 20A |
| discharge current |
≤ 40A |
| discharge overcurrent protection Current |
50A(10s), 80A(100ms) |
| Discharge cut-off voltage | 22V |
| cell specifications |
square 40Ah/lithium iron phosphate |
| finished product internal resistance |
≤ 30 Mohm |
| battery weight |
27Kg ± 5Kg |
| product Size |
L750mm*W160mm*H400mm(Max) |
| charging temperature protection |
0°C to 55°C |
| discharge temperature protection |
-20°C ~ 60°C |
| battery shell |
metal Shell |
| lithium battery protection |
|
| Communication mode |
RS485 & RS232 |
