model

16S60Ah-PC02-A

battery Specification

16S/48V/60Ah

nominal Voltage

51.2V

nominal capacity

charging voltage

58.4V

charging current

≤ 60A

discharge current

≤ 90A

instantaneous discharge current

≤ 180A

discharge cut-off voltage

43.2V

Cell specifications

32700/lithium iron phosphate cylinder cell

finished product internal resistance

≤ 100 Mohm

battery weight

32Kg ± 1Kg

product Size

l750mm*W284mm*H160(Max)

temperature Protection

55℃

Battery shell

sheet metal parts

lithium battery protection

short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, equalization, etc.

Communication mode

RS485 & RS232
