DGPI-RTV-004 60V Lithium Battery
time：2025-01-13
Parameters：
Specifications 20s50ah-dgpi-rtv-004
Brand Guarantee: optional Brand Cell
Long Life: battery Cycle Times> 2000
System Security: equipped with Smart BMS to Monitor the Battery Status in Real Time and Protect the Battery
Technical parameters
provide customized services
| model |
20S50Ah-DGPI-RTV-004 |
| nominal Voltage |
60V |
| nominal capacity |
50Ah |
| Charging current | ≤ 25A |
| discharge current |
≤ 50A |
| charging voltage |
73V |
| cell specifications |
lithium iron phosphate |
| finished product internal resistance |
≤ 150 Mohm |
| Battery weight | 30.0Kg ± 1.0Kg |
| product Size |
l370mm*W340mm*H180mm(Max) |
| communication mode |
RS232/RS485 |
| lithium battery protection |
short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, equalization, etc. |
